Alfred Kleusberg, Dr. Naser El-Sheimy, and Dr. David Wells for reviewing and/or commenting on the earlier version of the manuscript. xv TLFeBOOK TLFeBOOK Introduction to GPS 1 The Global Positioning System (GPS) is a satellite-based navigation system that was developed by the U.
Department of Defense (DoD) in the early 1970s. Initially, GPS was developed as a military system to fulfill U. mili- tary needs. However, it was later made available to civilians, and is now a dual-use system that can be accessed by both military and civilian users [1].
GPS provides continuous positioning and timing information, any- where in the world under any weather conditions. Because it serves an unlimited number of users as well as being used for security reasons, GPS is a one-way-ranging (passive) system [2]. That is, users can only receive the satellite signals. This chapter introduces the GPS system, its components, and its basic idea.1 Overview of GPS GPS consists, nominally, of a constellation of 24 operational satellites.
This constellation, known as the initial operational capability (IOC), was com- pleted in July 1993. The official IOC announcement, however, was made on December 8, 1993 [3]. To ensure continuous worldwide coverage, GPS 1 TLFeBOOK 2 Introduction to GPS satellites are arranged so that four satellites are placed in each of six orbital planes (Figure 1. With this constellation geometry, four to ten GPS sat- ellites will be visible anywhere in the world, if an elevation angle of 10° is considered.
As discussed later, only four satellites are needed to provide the positioning, or location, information. GPS satellite orbits are nearly circular (an elliptical shape with a maxi- mum eccentricity is about 0.01), with an inclination of about 55° to the equator. The semimajor axis of a GPS orbit is about 26,560 km (i., the sat- ellite altitude of about 20,200 km above the Earths surface) [4]. The corre- sponding GPS orbital period is about 12 sidereal hours (~11 hours, 58 minutes).
The GPS system was officially declared to have achieved full operational capability (FOC) on July 17, 1995, ensuring the availability of at least 24 operational, nonexperimental, GPS satellites. In fact, as shown in Section 1.4, since GPS achieved its FOC, the number of satellites in the GPS constellation has always been more than 24 operational satellites.2 GPS segments GPS consists of three segments: the space segment, the control segment, and the user segment (Figure 1. The space segment consists of the 24-satellite constellation introduced in the previous section. Each GPS sat- ellite transmits a signal, which has a number of components: two sine waves (also known as carrier frequencies), two digital codes, and a naviga- tion message.
The codes and the navigation message are added to the carri- ers as binary biphase modulations [5]. The carriers and the codes are used mainly to determine the distance from the users receiver to the GPS L-band antenna Solar panel S-band antenna Figure 1. TLFeBOOK Introduction to GPS 3 Space segment GPS signal Download (L-band) Upload (S-band) Control segment User segment Figure 1. The navigation message contains, along with other inform- ation, the coordinates (the location) of the satellites as a function of time.
The transmitted signals are controlled by highly accurate atomic clocks onboard the satellites. More about the GPS signal is given in Chapter 2. The control segment of the GPS system consists of a worldwide net- work of tracking stations, with a master control station (MCS) located in the United States at Colorado Springs, Colorado.
