These hybrid electric vehicles (HEVs) afford a reduction of fuel consumption in city driving and reduce emissions, but this is only the first stretch of a long road that will hopefully end with zero-emission electric vehicles (EVs) allowing long-range driving. The first vehicles produced at the beginning of the last century were electric, powered by lead-acid batteries, but they were soon abandoned because of the limited battery performance and the availability of fossil fuels at reasonable costs. However, the situation has radically changed in recent years; high fuel price and dramatic environ mental deterioration have led to reconsider the use of batteries, whose performance, on the other hand, has been steadily increasing since the early 1990s. Nickel-metal hydride (almost exclusively used to the end of 2009, e.
in Toyota Prius and Honda Insight) and the forthcoming Li-ion batteries (now used in recently produced electric vehicles, e. Nissan Leaf and Mitsubishi i-MiEV) have satisfactory energy and power features. In this book, the performance, cost, safety and sustainability of these and other battery systems for HEVs and EVs are thoroughly reviewed (parti cularly in Chapters 8 and 13–19). Attention is also given to fuel cell systems, as research in this area is more active than ever, and prototypes of hydrogen fuel cell vehicles are already circulating (e.
Honda FCX Clarity and GM Hydrogen4), although their cost places commercialization a long- way ahead (Chapters 9–12). Throughout this book, especially in the first chapters, alternative vehicles with different powertrains are compared in terms of lifetime cost, fuel consumption and environmental impact. The emissions of greenhouse gases have been particularly dealt with. In general, how far is, and how much substantial will be, the penetration of alter native vehicles into the market? The answer to this question has to be based on the assumption of models taking into account such factors as the fraction of electricity produced by renewable sources and the level of CO2 considered acceptable (as is done especially in Chapters 4 and 21).
However, according to some surveys, many drivers seem less attracted by environmental issues and more by vehicle performance and cost. In this respect, improvement of the battery, or fuel cell, performance and governmental incentives will play a fundamental role. An adequate recharging infrastructure is also of paramount importance for the diffusion of vehicles powered by batteries and fuel cells, as it may contribute to overcome xvii xviii Preface the so-called “range anxiety”. The battery charging techniques proposed are summarized in Chapter 20, while hydrogen refueling stations are described in Chapter 12.
Finally, in Chapter 22, the state of the art of the current models of hybrid and electric vehicles (as of the beginning of 2010) is reviewed along with the powertrain solutions adopted by the major automakers. Gianfranco Pistoia CHAPTER ONE Economic and Environmental Comparison of Conventional and Alternative Vehicle Options Ibrahim Dincer1, Marc A. Rosen and Calin Zamfirescu Faculty of Engineering and Applied Science, University of Ontario, Institute of Technology (UOIT), Oshawa, Ontario, Canada Contents 1.1 Technical and economical criteria 3 2.2 Environmental impact criteria 5 2.3 Normalization and the general indicator 10 3. Results and Discussion 11 4.
Conclusions 15 Acknowledgement 15 Nomenclature 16 Greek symbols 16 Subscripts 16 References 16 1. INTRODUCTION Of the major industries that have to adapt and reconfigure to meet present requirements for sustainable development, vehicle manufacturing is one of the more significant. One component of sustainability requires the design of environmentally benign vehicles characterized by no or little atmospheric pollution during operation. The design of such vehicles requires, among other developments, improvements in powertrain systems, fuel processing, and power conversion technologies.
Opportunities for utilizing various fuels for vehicle propulsion, with an emphasis on synthetic fuels (e., hydrogen, biodiesel, bioethanol, dimethylether, ammonia, etc.) as well as electri city via electrical batteries, have been analyzed over the last decade and summarized in Refs [1–3]. In analyzing a vehicle propulsion and fueling system, it is necessary to consider all stages of the life cycle starting from the extraction of natural resources to produce 1 Corresponding author: Ibrahim.ca Electric and Hybrid Vehicles © 2010 Elsevier B.00001-4 All rights reserved. 1 2 Ibrahim Dincer et al. materials and ending with conversion of the energy stored onboard the vehicle into mechanical energy for vehicle displacement and other purposes (heating, cooling, lighting, etc.
All life cycle stages preceding fuel utilization on the vehicle influence the overall efficiency and environmental impact. In addition, vehicle production stages and end-of-life disposal contribute substantially when quantifying the life cycle envir onmental impact of fuel-propulsion alternatives. Cost-effectiveness is also a decisive factor contributing to the development of an environmentally benign transportation sector. This chapter extends and updates the approach by Granovskii et al.
[1] which evaluates, based on actual cost data, the life cycle indicators for vehicle production and utilization stages and performs a comparison of four kinds of fuel-propulsion vehicle alternatives. We consider in the present analysis two additional kinds of vehicles, both of which are zero polluting at fuel utilization stage (during vehicle operation). One uses hydrogen as a fuel in an internal combustion engine (ICE), while the second uses ammonia as a hydrogen fuel source to drive an ICE.
